logger Class Reference
[Log recording module]

#include <recorder_functions.h>

Collaboration diagram for logger:

Data Structures
struct	struct_file_handle
struct	struct_message
struct	struct_message_types
struct	struct_sensor
Public Member Functions
	logger ()
	Constructor for the logger class.
	~logger ()
	Deconstructur for the logger class.
int	ReadFormatsFromFile (void)
	Read messages formats from a XML file.
int	SetLogFiles (const char *filename)
	This function sets the log file that will be used This function checks if the filename passed by already exists and if so, the filename will be append with _A, if that file also exist we test the next char, and so on.
int	StartLog (void)
	This function start the log parser This function creates a new log parser and sets the begin of the XML log header.
void	InstallParameters (int argc, char **argv)
	This function install all recorder parameters This function mallocs the number of parameters corresponding to the message types in the MESSAGE_TYPES_FILE and install them. This function also sets the param deamon to allow unfound variables.
int	WriteHeader (void)
	Write log header This function writes the log header, the header constains, list of sessions, list of sensors and list of messages.
int	CloseLog (void)
	Close Log file This function cleans the XML parser and dumps memory, it also closes all data files.
int	GetSensors (void)
	This function obtains the list of sensors This function obtains the list of sensors to be used in this log, for now this is just a dummy function.
int	InitMessageLoging (void)
	Writes the begin of the messages element This function writes the begin of the messages element of the log.
void	InitMessageTypes ()
int	AddMessage ()
	Addes a single message to the log header This function addes a new entry to the log header. Message format is m=message, t=message_type sp=start_position, l=length, c=comment.
void	SubscribeMessages ()
	Subscribe IPC Messages This function subscribes all the predefined message types.
int	UpdateStatistics (void)
	Updade a posteriory statistics This function updates the log header with a posteriory statistics, it opens the file again parses it and updates the correct fields using Xpath.
Data Fields
struct_message	current_message
	Most recent message recived.
double	log_start_time
	Start timestamp of the log.
unsigned int	total_message_types
	Total message types being logged.
struct_message_types *	message_types
	Message types being logged.
long int	total_number_messages
	Total number of messages of the log.
Private Types
enum	enum_write_mode { SEQUENCIAL, TREE }
Private Member Functions
int	WriteMessageTypes (void)
	Write a list of all message types This function writes a list of all message types to be logged.
int	WriteSession (void)
	Write session This function writes a log session onto a file. The log session contains the time and data of the log, the computer name, the session id, the start and end location, the driver of the car, car odometer information and weather conditions.
int	WriteSensorList (void)
	Write sensor list This function writes a sensor list onto the log.
int	WriteSensor (unsigned int number)
	Write a single sensor This function writes a single sensor into the log. Sensor are obtained using logger::GetSensors, sensor information contain: id, type, vendor, data interface, placement and if it a camera it also contains focal distance and resolution.
Private Attributes
struct_file_handle	file_handle
	Handler to control file acess.
unsigned int	number_sensors
	Total number of sensors.
struct_sensor *	sensors
	Sensor list.
unsigned int	session_id
	Id of this session.
char	encoding [512]
	Encoding used in the XML file.
bool	save_on_add
	This variable indicates if we save the log on each message add.
bool	compression
	Use compression in FILE write mode.
xmlNodePtr	node
	Auxiliar variable.
xmlChar *	tmp
	Auxiliar variable.
enum_write_mode	write_mode
	Writing method associated with XmlWriter.
char	text [512]
	Auxiliar variable.
int	rc
	return code used in libxml2 functions
double	mtf_version
	Message types file version.
double	log_version
	Recorder program version.

Member Enumeration Documentation

enum logger::enum_write_mode [private]

Enumerator:

SEQUENCIAL	Sequencial write mode, in this mode there's no memory buffer of the tree so the file is always up to date.
TREE	Tree write mode, in this mode a tree of the log is stored in memory so we must write the file to memory manualy.
